Appendix D: Modbus I/O Assignments
76 Manual Documentation Number: pn7515_ZlinxIO-0712m
Modbus Address Description #Bytes Count V Range
00065 EXP-4 Digital Output-1 - 0-1 Refer to Appendix B
00066 EXP-4 Digital Output-2 - 0-1 Refer to Appendix B
00067 EXP-4 Digital Output-3 - 0-1 Refer to Appendix B
00068 EXP-4 Digital Output-4 - 0-1 Refer to Appendix B
00069 EXP-4 Digital Output-5 - 0-1 Refer to Appendix B
00070 EXP-4 Digital Output-6 - 0-1 Refer to Appendix B
00071 EXP-4 Digital Output-7 - 0-1 Refer to Appendix B
00072 EXP-4 Digital Output-8 - 0-1 Refer to Appendix B
00073 EXP-4 Digital Output-9 - 0-1 Refer to Appendix B
00074 EXP-4 Digital Output-10 - 0-1 Refer to Appendix B
00075 EXP-4 Digital Output-11 - 0-1 Refer to Appendix B
00076 EXP-4 Digital Output-12 - 0-1 Refer to Appendix B
00077 EXP-4 Digital Output-13 - 0-1 Refer to Appendix B
00078 EXP-4 Digital Output-14 - 0-1 Refer to Appendix B
00079 EXP-4 Digital Output-15 - 0-1 Refer to Appendix B
00080 EXP-4 Digital Output-16 - 0-1 Refer to Appendix B
00081 EXP-5 Digital Output-1 - 0-1 Refer to Appendix B
00082 EXP-5 Digital Output-2 - 0-1 Refer to Appendix B
00083 EXP-5 Digital Output-3 - 0-1 Refer to Appendix B
00084 EXP-5 Digital Output-4 - 0-1 Refer to Appendix B
00085 EXP-5 Digital Output-5 - 0-1 Refer to Appendix B
00086 EXP-5 Digital Output-6 - 0-1 Refer to Appendix B
00087 EXP-5 Digital Output-7 - 0-1 Refer to Appendix B
00088 EXP-5 Digital Output-8 - 0-1 Refer to Appendix B
00089 EXP-5 Digital Output-9 - 0-1 Refer to Appendix B
00090 EXP-5 Digital Output-10 - 0-1 Refer to Appendix B
00091 EXP-5 Digital Output-11 - 0-1 Refer to Appendix B
00092 EXP-5 Digital Output-12 - 0-1 Refer to Appendix B
00093 EXP-5 Digital Output-13 - 0-1 Refer to Appendix B
00094 EXP-5 Digital Output-14 - 0-1 Refer to Appendix B
00095 EXP-5 Digital Output-15 - 0-1 Refer to Appendix B
00096 EXP-5 Digital Output-16 1 0-1 Refer to Appendix B
00097 EXP-6 Digital Output-1 - 0-1 Refer to Appendix B
00098 EXP-6 Digital Output-2 - 0-1 Refer to Appendix B
00099 EXP-6 Digital Output-3 - 0-1 Refer to Appendix B
00100 EXP-6 Digital Output-4 - 0-1 Refer to Appendix B
00101 EXP-6 Digital Output-5 - 0-1 Refer to Appendix B
00102 EXP-6 Digital Output-6 - 0-1 Refer to Appendix B
00103 EXP-6 Digital Output-7 - 0-1 Refer to Appendix B
00104 EXP-6 Digital Output-8 - 0-1 Refer to Appendix B
00105 EXP-6 Digital Output-9 - 0-1 Refer to Appendix B
00106 EXP-6 Digital Output-10 - 0-1 Refer to Appendix B
00107 EXP-6 Digital Output-11 - 0-1 Refer to Appendix B
00108 EXP-6 Digital Output-12 - 0-1 Refer to Appendix B
00109 EXP-6 Digital Output-13 - 0-1 Refer to Appendix B
00110 EXP-6 Digital Output-14 - 0-1 Refer to Appendix B
00111 EXP-6 Digital Output-15 - 0-1 Refer to Appendix B
00112 EXP-6 Digital Output-16 - 0-1 Refer to Appendix B
10001-10112 Discrete Digital Inputs
Modbus Address Description #Bytes Count V Range
10001 Base Digital Input-1 - 0-1 Refer to Appendix B
10002 Base Digital Input-2 - 0-1 Refer to Appendix B
10003 Base Digital Input-3 - 0-1 Refer to Appendix B
10004 Base Digital Input-4 - 0-1 Refer to Appendix B
10005 Base Digital Input-5 - 0-1 Refer to Appendix B
10006 Base Digital Input-6 - 0-1 Refer to Appendix B
10007 Base Digital Input-7 - 0-1 Refer to Appendix B
10008 Base Digital Input-8 - 0-1 Refer to Appendix B
10009 Base Digital Input-9 - 0-1 Refer to Appendix B
10010 Base Digital Input-10 - 0-1 Refer to Appendix B
10011 Base Digital Input-11 - 0-1 Refer to Appendix B
10012 Base Digital Input-12 - 0-1 Refer to Appendix B
10013 Base Digital Input-13 - 0-1 Refer to Appendix B
10014 Base Digital Input-14 - 0-1 Refer to Appendix B
10015 Base Digital Input-15 - 0-1 Refer to Appendix B
10016 Base Digital Input-16 - 0-1 Refer to Appendix B
10017 EXP-1 Digital Input-1 - 0-1 Refer to Appendix B
10018 EXP-1 Digital Input-2 - 0-1 Refer to Appendix B
10019 EXP-1 Digital Input-3 - 0-1 Refer to Appendix B
10020 EXP-1 Digital Input-4 - 0-1 Refer to Appendix B
10021 EXP-1 Digital Input-5 - 0-1 Refer to Appendix B
10022 EXP-1 Digital Input-6 - 0-1 Refer to Appendix B
10023 EXP-1 Digital Input-7 - 0-1 Refer to Appendix B
10024 EXP-1 Digital Input-8 - 0-1 Refer to Appendix B
10025 EXP-1 Digital Input-9 - 0-1 Refer to Appendix B
10026 EXP-1 Digital Input-10 - 0-1 Refer to Appendix B
10027 EXP-1 Digital Input-11 - 0-1 Refer to Appendix B
10028 EXP-1 Digital Input-12 - 0-1 Refer to Appendix B
