Appendix D: Modbus I/O Assignments
78
Manual Documentation Number: pn7515_ZlinxIO-0712m
Modbus Address
Description
#Bytes
Count
V Range
10108
EXP-6 Digital Input-12
-
0-1
Refer to Appendix B
10109
EXP-6 Digital Input-13
-
0-1
Refer to Appendix B
10110
EXP-6 Digital Input-14
-
0-1
Refer to Appendix B
10111
EXP-6 Digital Input-15
-
0-1
Refer to Appendix B
10112
EXP-6 Digital Input-16
-
0-1
Refer to Appendix B
30001-30112 Analog Inputs
Modbus Address
Description
#Bytes
A/D Count
(V)/(I)Range
30001
Base Analog Input-1
2
0-4095
0-10vdc/0-20ma
30002
Base Analog Input-2
2
0-4095
0-10vdc/0-20ma
30003
Base Analog Input-3
2
0-4095
0-10vdc/0-20ma
30004
Base Analog Input-4
2
0-4095
0-10vdc/0-20ma
30005
System Input Power
2
0-1023
0-40vdc
30006
Base Analog Input-6
2
0-4095
0-10vdc/0-20ma
30007
Base Analog Input-7
2
0-4095
0-10vdc/0-20ma
30008
Base Analog Input-8
2
0-4095
0-10vdc/0-20ma
30009
Base Reserved
-
-
-
30010
Base Reserved
-
-
-
30011
Base Reserved
-
-
-
30012
Base Reserved
-
-
-
30013
Base Reserved
-
-
-
30014
Base Reserved
-
-
-
30015
Base Reserved
-
-
-
30016
Base Reserved
-
-
-
30017
EXP-1 Analog Input-1
2
0-4095/0-65535
0-10vdc/0-20ma/RTD*
30018
EXP-1 Analog Input-2
2
0-4095/0-65535
0-10vdc/0-20ma/RTD*
30019
EXP-1 Analog Input-3
2
0-4095/0-65535
0-10vdc/0-20ma/RTD*
30020
EXP-1 Analog Input-4
2
0-4095/0-65535
0-10vdc/0-20ma/RTD*
30021
EXP-1 Analog Input-5
2
0-4095
0-10vdc/0-20ma
30022
EXP-1 Analog Input-6
2
0-4095
0-10vdc/0-20ma
30023
EXP-1 Analog Input-7
2
0-4095
0-10vdc/0-20ma
30024
EXP-1 Analog Input-8
2
0-4095
0-10vdc/0-20ma
30025
EXP-1 Reserved
-
-
-
30026
EXP-1 Reserved
-
-
-
30027
EXP-1 Reserved
-
-
-
30028
EXP-1 Reserved
-
-
-
30029
EXP-1 Reserved
-
-
-
30030
EXP-1 Reserved
-
-
-
30031
EXP-1 Reserved
-
-
-
30032
EXP-1 Reserved
-
-
-
30033
EXP-2 Analog Input-1
2
0-4095
0-10vdc/0-20ma
30034
EXP-2 Analog Input-2
2
0-4095
0-10vdc/0-20ma
30035
EXP-2 Analog Input-3
2
0-4095
0-10vdc/0-20ma
30036
EXP-2 Analog Input-4
2
0-4095
0-10vdc/0-20ma
30037
EXP-2 Analog Input-5
2
0-4095
0-10vdc/0-20ma
30038
EXP-2 Analog Input-6
2
0-4095
0-10vdc/0-20ma
30039
EXP-2 Analog Input-7
2
0-4095
0-10vdc/0-20ma
30040
EXP-2 Analog Input-8
2
0-4095
0-10vdc/0-20ma
30041
EXP-2 Reserved
-
-
-
30042
EXP-2 Reserved
-
-
-
30043
EXP-2 Reserved
-
-
-
30044
EXP-2 Reserved
-
-
-
30045
EXP-2 Reserved
-
-
-
30046
EXP-2 Reserved
-
-
-
30047
EXP-2Reserved
-
-
-
30048
EXP-2 Reserved
-
-
-
30049
EXP-3 Analog Input-1
2
0-4095
0-10vdc/0-20ma
30050
EXP-3 Analog Input-2
2
0-4095
0-10vdc/0-20ma
30051
EXP-3 Analog Input-3
2
0-4095
0-10vdc/0-20ma
30052
EXP-3 Analog Input-4
2
0-4095
0-10vdc/0-20ma
30053
EXP-3 Analog Input-5
2
0-4095
0-10vdc/0-20ma
30054
EXP-3 Analog Input-6
2
0-4095
0-10vdc/0-20ma
30055
EXP-3 Analog Input-7
2
0-4095
0-10vdc/0-20ma
30056
EXP-3 Analog Input-8
2
0-4095
0-10vdc/0-20ma
30057
EXP-3 Reserved
-
-
-
30058
EXP-3 Reserved
-
-
-
30059
EXP-3 Reserved
-
-
-
30060
EXP-3 Reserved
-
-
-
30061
EXP-3 Reserved
-
-
-
30062
EXP-3 Reserved
-
-
-
30063
EXP-3Reserved
-
-
-
30064
EXP-3 Reserved
-
-
-
30065
EXP-4 Analog Input-1
2
0-4095
0-10vdc/0-20ma
30066
EXP-4 Analog Input-2
2
0-4095
0-10vdc/0-20ma
30067
EXP-4 Analog Input-3
2
0-4095
0-10vdc/0-20ma
30068
EXP-4 Analog Input-4
2
0-4095
0-10vdc/0-20ma
30069
EXP-4 Analog Input-5
2
0-4095
0-10vdc/0-20ma
