Setup
36 Manual Documentation Number: pn7515_ZlinxIO-0712m
The Zlinx I/O Configuration window contains:
 File and Help menus.
 Three tabbed panes: Information, Configuration, and Input/Output.
 A Help sidebar containing information and hints related to the current tab. If the sidebar is not visible enable it by
going to Help > Sidebar.
 A graphic display of the Base and Expansion Modules discovered.
 A Status bar (at the bottom) showing the COM port and communications parameters: baud rate, parity, data bits, stop
bits and flow control.
 An Update button used to save configuration parameters to the modules.
 An Exit button.
