Appendix E: Zlinx Wireless I/O Models and Features
82
Manual Documentation Number: pn7515_ZlinxIO-0712m
A
A
p
p
p
p
e
e
n
n
d
d
i
i
x
x
E
E
:
:
Z
Z
l
l
i
i
n
n
x
x
W
W
i
i
r
r
e
e
l
l
e
e
s
s
s
s
I
I
/
/
O
O
M
M
o
o
d
d
e
e
l
l
s
s
a
a
n
n
d
d
F
F
e
e
a
a
t
t
u
u
r
r
e
e
s
s
Base Modules
Model Number
Module Type
Frequency/Range
I/O
ZZ24D-NA-SR
Base
2.4 GHz, short
range
2AI, 2AO, 2DI,
2DO
(sourcing DO’s)
ZZ24D-NB-SR
Base
2.4 GHz, short
range
4DI, 4DO
(sourcing DO’s)
ZZ24D-NC-SR
Base
2.4 GHz, short
range
2AI, 2AO, 2DI,
2DO
(sinking DO’s)
ZZ24D-ND-SR
Base
2.4 GHz, short
range
4DI, 4DO
(sinking DO’s)
ZZ24D-NA-MR
Base/Repeater
2.4 GHz, medium
range
2AI, 2AO, 2DI,
2DO
(sourcing DO’s)
ZZ24D-NB-MR
Base/Repeater
2.4 GHz, medium
range
4DI, 4DO
(sourcing DO’s)
ZZ24D-NC-MR
Base/Repeater
2.4 GHz, medium
range
2AI, 2AO, 2DI,
2DO
(sinking DO’s)
ZZ24D-ND-MR
Base/Repeater
2.4 GHz, medium
range
4DI, 4DO
(sinking DO’s)
ZZ9D-NA-MR
Base/Repeater
900 MHz, medium
range
2AI, 2AO, 2DI,
2DO
(sourcing DO’s)
ZZ9D-NB-MR
Base/Repeater
900 MHz, medium
range
4DI, 4DO
(sourcing DO’s)
ZZ9D-NC-MR
Base/Repeater
900 MHz, medium
range
2AI, 2AO, 2DI,
2DO
(sinking DO’s)
ZZ9D-ND-MR
Base/Repeater
900 MHz, medium
range
4DI, 4DO
(sinking DO’s)
ZZ9D-NA-LR
Base/Repeater
900 MHz, long
range
2AI, 2AO, 2DI,
2DO
(sourcing DO’s)
ZZ9D-NB-LR
Base/Repeater
900 MHz, long
range
4DI, 4DO
(sourcing DO’s)
ZZ9D-NC-LR
Base/Repeater
900 MHz, long
range
2AI, 2AO, 2DI,
2DO
(sinking DO’s)
ZZ9D-ND-LR
Base/Repeater
900 MHz, long
range
4DI, 4DO
(sinking DO’s)
