Configuration & Operation
38
Manual Documentation Number: pn7515_ZlinxIO-0712m
5
5
.
.
C
C
o
o
n
n
f
f
i
i
g
g
u
u
r
r
a
a
t
t
i
i
o
o
n
n
&
&
O
O
p
p
e
e
r
r
a
a
t
t
i
i
o
o
n
n
Zlinx I/O Configuration software is used to configure Zlinx Wireless I/O hardware. Using Zlinx I/O Configuration, the system
can be configured to operate in Peer-to-Peer (wire-replacement) or Modbus modes receiving Modbus commands and data
from a Modbus wireless modem. Digital Inputs can be configured to operate in Discrete (on/off) or Counter modes, and
Analog Inputs and Outputs are configurable for voltage or current loop operation.
5.1 Configuring Zlinx Wireless I/O
To enable the features described below (except Monitor):
1. Start Zlinx Manager.
2. Choose Zlinx I/O Configuration (See Section 4.5 for more details).
3. The features are enabled and parameters for them are set in Configuration tab.
Zlinx Wireless I/O modules can be configured to operate as wireless Modbus nodes or as wire replacement links in Peer-to-
Peer mode. Wireless configuration options are the same for either mode.
5.1.1 Wireless Settings
Zlinx Wireless I/O Base Modules can be configured for operation with different transmitter output power. They can also be
configured to operate on several different radio channels. This allows multiple Zlinx Wireless I/O systems to operate in the
same area without interference. The number of different systems can be further increased by configuring a unique Network
Identifier (which selects the frequency hopping sequence). Base Modules also can be used as repeaters, to extend the range
of a system. Over-the-air (OTA) data rated can also be adjusted to increase range. A lower OTA data rate will increase the
effective range of the radio, but will also increase the total throughput time.
Firmware Version 3.19 and higher supports the following features
Base Module
Transmit Power Selectable
RF OTA Data Rate
AES Encryption
SR
YES
NO
128 BIT
MR
NO
NO
NO
LR
YES
YES
256 BIT
LR-AU
YES
YES
128 BIT
ZZ8D-xx-LR (868 MHz)
YES
NO
128 BIT
