Configuration & Operation
40 Manual Documentation Number: pn7515_ZlinxIO-0712m
3. Set the Channel Number field to match the channel used by the device with which it will communicate.
a. If that device is another Zlinx Wireless I/O Base Module, set the Channel Numbers the same when configuring each of
them.
b. If the device is a Modbus radio modem, the modem must be configured by using Zlinx Radio Modem Configuration to
match the Base Module’s Channel Number.
c. Each Zlinx Wireless I/O radio type uses a different Channel Number range. Modbus radio modems should be
configured using Radio Modem Configuration depending on the radio type. The table below shows these ranges and
commands in hexadecimal values:
Type/Range Base Module
Channel Number
Range
Short Range (SR) 0x0C to 0x17
Medium Range (MR) 0x00 to 0x06
ZZ8D-Nx-LR Single Channel
ZZ9D-Nx-LR-xx 0x00 to 0x09
Figure 34 Radio Types, Channel Numbers
NOTE: The default value of the Channel Number field for SR radios is 0x0C; the
default for MR and ZZ9D-Nx-LR-xx radios is 0x00.
4. Set the Network Identifier field to match the Identifier used by the device with which it will communicate.
a. If that device is another Zlinx Wireless I/O Base Module, set the Network Identifiers the same when configuring each
of them.
b. If the device is a Modbus radio modem, the modem must be configured by using Zlinx Radio Modem Configuration o
match the Base Module’s Network Identifier.
c. Each Zlinx Wireless I/O radio type uses a different Network Identifier range. The table below shows the channel
number ranges in hexadecimal values.
Type/Range Base Module Network
Identifier Range
Short Range (SR) 0x00 to 0xFF
Medium Range (MR) 0x10 to 0xFF
ZZ8D-Nx-LR 0x00 to 0xFF
ZZ9D-Nx-LR-xx 0x11 to 0xFF
Figure 35 Network ID Value Table
The default value of the Channel Number field for SR radios and ZZ8D-Nx-LR radios is 0x00; the default for MR radios is
0x10 and for ZZ9D-Nx-LR-xx radios is 0x11.
d. If the device is a Modbus radio modem, for MR and ZP9D-Nx-LR-xx radio modems set the destination address to
0xFFFF using the Zlinx Configuration Manager.
