background image

Appendix A: Default Configuration Settings

70

Manual Documentation Number: pn7515_ZlinxIO-0712m

A

A

p

p

p

p

e

e

n

n

d

d

i

i

x

x

A

A

:

:

D

D

e

e

f

f

a

a

u

u

l

l

t

t

C

C

o

o

n

n

f

f

i

i

g

g

u

u

r

r

a

a

t

t

i

i

o

o

n

n

S

S

e

e

t

t

t

t

i

i

n

n

g

g

s

s

Power Setting: SR Base Modules, 63mW, MR Base Modules, 50mW,

LR Bae Modules, 1000mW, ZZ8D-xx-LR Base
Modules, 316mW

Wireless Channel

Number:

0x0C for SR Base Modules
0x00 for MR and ZZ9D-Nx-LR-xx Base Modules
Single Channel for the ZZ8D-Nx-LR Base Modules

Wireless Network ID: 0x00 for SR Base Modules

0x10 for MR Base Modules
0x11 for ZZ9D-Nx-LR-xx Base Modules
0x00 for ZZ8D-Nx-LR Base Modules

Repeater Mode: Not selected

Communication Mode: Modbus

Modbus Address: 1

Digital Inputs: Discrete

Analog Inputs: 0 to 10 VDC

Analog Outputs: 0 to 10 VDC
