Appendix D: Modbus I/O Assignments

Manual Documentation Number: pn7515_ZlinxIO-0712m

81

Modbus Address

Description

#Bytes

D/A Count

(V)/(I)Range

40102

EXP-6 Analog Output-6

2

0-4095

0-10vdc/0-20ma

40103

EXP-6 Analog Output-7

2

0-4095

0-10vdc/0-20ma

40104

EXP-6 Analog Output-8

2

0-4095

0-10vdc/0-20ma

40105

EXP-6 Freq Input – 1

2

0-5000

0-5000Hz

40106

EXP-6 Freq Input – 2

2

0-5000

0-5000Hz

40107

EXP-6 Reserved

-

-

-

40108

EXP-6 Reserved

-

-

-

40109

EXP-6 Address

2

0-1023

40110

EXP-6 Reserved

-

-

-

40111

EXP-6 Reserved

-

-

-

40112

EXP-6 Reserved

-

-

-
