Appendix D: Modbus I/O Assignments
Manual Documentation Number: pn7515_ZlinxIO-0712m 75
A A p p p p e e n n d d i i x x D D : : M M o o d d b b u u s s I I / / O O A A s s s s i i g g n n m m e e n n t t s s
00001-00112 Discrete Digital Outputs
Modbus function codes supported are:
Function 1: Read DO Status
Function 2: Read DI’s
Function 3: Read AO Status
Function 4: Read AI’s
Function 5: Write to Single DO (firmware v2.0 or higher)
Function 6: Write to Single AO
Function 15: Write to Multi DO’s
Modbus Address Description #Bytes Count V Range
00001 Base Digital Output-1 - 0-1 Refer to Appendix B
00002 Base Digital Output-2 - 0-1 Refer to Appendix B
00003 Base Digital Output-3 - 0-1 Refer to Appendix B
00004 Base Digital Output-4 - 0-1 Refer to Appendix B
00005 Base Digital Output-5 - 0-1 Refer to Appendix B
00006 Base Digital Output-6 - 0-1 Refer to Appendix B
00007 Base Digital Output-7 - 0-1 Refer to Appendix B
00008 Base Digital Output-8 - 0-1 Refer to Appendix B
00009 Base Digital Output-9 - 0-1 Refer to Appendix B
00010 Base Digital Output-10 - 0-1 Refer to Appendix B
00011 Base Digital Output-11 - 0-1 Refer to Appendix B
00012 Base Digital Output-12 - 0-1 Refer to Appendix B
00013 Base Digital Output-13 - 0-1 Refer to Appendix B
00014 Base Digital Output-14 - 0-1 Refer to Appendix B
00015 Base Digital Output-15 - 0-1 Refer to Appendix B
00016 Base Digital Output-16 - 0-1 Refer to Appendix B
00017 EXP-1 Digital Output-1 - 0-1 Refer to Appendix B
00018 EXP-1 Digital Output-2 - 0-1 Refer to Appendix B
00019 EXP-1 Digital Output-3 - 0-1 Refer to Appendix B
00020 EXP-1 Digital Output-4 - 0-1 Refer to Appendix B
00021 EXP-1 Digital Output-5 - 0-1 Refer to Appendix B
00022 EXP-1 Digital Output-6 - 0-1 Refer to Appendix B
00023 EXP-1 Digital Output-7 - 0-1 Refer to Appendix B
00024 EXP-1 Digital Output-8 - 0-1 Refer to Appendix B
00025 EXP-1 Digital Output-9 - 0-1 Refer to Appendix B
00026 EXP-1 Digital Output-10 - 0-1 Refer to Appendix B
00027 EXP-1 Digital Output-11 - 0-1 Refer to Appendix B
00028 EXP-1 Digital Output-12 - 0-1 Refer to Appendix B
00029 EXP-1 Digital Output-13 - 0-1 Refer to Appendix B
00030 EXP-1 Digital Output-14 - 0-1 Refer to Appendix B
00031 EXP-1 Digital Output-15 - 0-1 Refer to Appendix B
00032 EXP-1 Digital Output-16 - 0-1 Refer to Appendix B
00033 EXP-2 Digital Output-1 - 0-1 Refer to Appendix B
00034 EXP-2 Digital Output-2 - 0-1 Refer to Appendix B
00035 EXP-2 Digital Output-3 - 0-1 Refer to Appendix B
00036 EXP-2 Digital Output-4 - 0-1 Refer to Appendix B
00037 EXP-2 Digital Output-5 - 0-1 Refer to Appendix B
00038 EXP-2 Digital Output-6 - 0-1 Refer to Appendix B
00039 EXP-2 Digital Output-7 - 0-1 Refer to Appendix B
00040 EXP-2 Digital Output-8 - 0-1 Refer to Appendix B
00041 EXP-2 Digital Output-9 - 0-1 Refer to Appendix B
00042 EXP-2 Digital Output-10 - 0-1 Refer to Appendix B
00043 EXP-2 Digital Output-11 - 0-1 Refer to Appendix B
00044 EXP-2 Digital Output-12 - 0-1 Refer to Appendix B
00045 EXP-2 Digital Output-13 - 0-1 Refer to Appendix B
00046 EXP-2 Digital Output-14 - 0-1 Refer to Appendix B
00047 EXP-2 Digital Output-15 - 0-1 Refer to Appendix B
00048 EXP-2 Digital Output-16 - 0-1 Refer to Appendix B
00049 EXP-3 Digital Output-1 - 0-1 Refer to Appendix B
00050 EXP-3 Digital Output-2 - 0-1 Refer to Appendix B
00051 EXP-3 Digital Output-3 - 0-1 Refer to Appendix B
00052 EXP-3 Digital Output-4 - 0-1 Refer to Appendix B
00053 EXP-3 Digital Output-5 - 0-1 Refer to Appendix B
00054 EXP-3 Digital Output-6 - 0-1 Refer to Appendix B
00055 EXP-3 Digital Output-7 - 0-1 Refer to Appendix B
00056 EXP-3 Digital Output-8 - 0-1 Refer to Appendix B
00057 EXP-3 Digital Output-9 - 0-1 Refer to Appendix B
00058 EXP-3 Digital Output-10 - 0-1 Refer to Appendix B
00059 EXP-3 Digital Output-11 - 0-1 Refer to Appendix B
00060 EXP-3 Digital Output-12 - 0-1 Refer to Appendix B
00061 EXP-3 Digital Output-13 - 0-1 Refer to Appendix B
00062 EXP-3 Digital Output-14 - 0-1 Refer to Appendix B
00063 EXP-3 Digital Output-15 - 0-1 Refer to Appendix B
00064 EXP-3 Digital Output-16 - 0-1 Refer to Appendix B
