Play/Pause
Position
Indicator
Timecode Value Color
Pause On or between IN
and OUT points Count down to the OUT point White
Pause Before IN point Count down to the IN point White
Pause After OUT point Duration from the OUT point Grey
Play On or between IN
and OUT points Count down to the OUT point Yellow
Play Before IN point Count down of the remaining time to
the OUT point White
Play After OUT point Count down of the remaining time to
the end of guardband (Protect OUT
point) White
When a Record Train is Loaded
The following table shows the possible colors and meanings of the Remaining Time /
Capacity field when a train is loaded.
The Remaining Time / Capacity field value and color depends on:
• whether the train is playing or paused
• whether an IN and/or OUT points are defined
• the media position indicator.
Play/Pause
IN/OUT
Point Position
Indicator
Timecode Value Color
Play No IN, no
OUT On the head of
record train Recording capacity
left on the train Blue
Play/Pause No IN, no
OUT Before the head of
record train Delay time from the
head of record train Yellow
Play/Pause Only IN
defined Before IN point Duration to IN point White
Play/Pause Only IN
defined After IN point Duration from IN point Yellow
Play/Pause Only OUT
defined Before OUT point Duration to OUT point Yellow
Play/Pause Only OUT
defined After OUT point Duration from OUT
point White
Play/Pause IN and OUT
defined Before IN point Duration to IN point White
Pause IN and OUT
defined On or between IN
and OUT point Duration between IN
and OUT points Yellow
Play IN and OUT Between IN and Countdown to OUT Yellow
22 5. Player
EVS Broadcast Equipment S.A. - June 2013 Issue 6.2.A
