Area Description / See section...
1. Locators (various
colors) See section "Using Locators" in the chapter on IPEdit.
2. TLO Nowline The nowline of the on-air timeline is displayed in red.
3. Security zone (red) The TLO Security zone is the portion of the timeline
after the TLO nowline on which the Timeline Engine will
not be able to commit changes from the TLE to the
TLO. This zone is defined by the Timeline Engine.
4. Full Timeline (blue) Graphical representation of the full TLE duration.
5. TLE portion visible in
Timeline display
(white) Graphical representation of the TLE portion currently
visible in the timeline.
6. TLE Nowline The nowline of the edit timeline is displayed in blue, as
usual in IPEdit.
The TLO preview bar is refreshed after a commit, and the nowline moves in real time.
Lock Button
When the user clicks the Lock button , it turns to . This means the PGM1/2 are
locked, and the Transport Control commands and COMMIT button are no longer available.
When the user clicks again the Lock button, it unlocks the PGM1/2, and the commands
become available again. The lock on the player channels is however preserved, as usual.
Transport Command Bar
Operation
User Interface
Button
Description
TLO Recue Clicking TLO Recue button loads the on-air timeline
on the first frame of the first element.
TLO Pause Clicking the TLO Pause button stops the playout of
the TLO at the current position.
TLO Play Clicking the TLO Play button starts the playout of the
TLO from the nowline position.
