Chapter 7 Basic Setting
GS-3012/GS-3012F User’s Guide
78
Figure 33 IP Setup
The following table describes the labels in this screen.
Table 11 IP Setup
LABEL DESCRIPTION
Domain Name
Server
DNS (Domain Name System) is for mapping a domain name to its
corresponding IP address and vice versa. Enter a domain name server IP
address in order to be able to use a domain name instead of an IP address.
Default
Management
Specify which traffic flow (In-Band or Out-of-band) the switch is to send
packets originating from itself (such as SNMP traps) or packets with unknown
source.
Select Out-of-band to have the switch send the packets to the out-of-band
management port. This means that device(s) connected to the other port(s) do
not receive these packets.
Select In-Band to have the switch send the packets to all ports except the out-
of-band management port to which connected device(s) do not receive these
packets.
In-Band Management IP Address
