Chapter 34 IEEE 802.1Q Tagged VLAN Commands
GS-3012/GS-3012F User’s Guide
258
34.3 Configuring Tagged VLAN
The following procedure shows you how to configure tagged VLAN.
1 Use the IEEE 802.1Q tagged VLAN commands to configure tagged VLAN for the
switch.
2 Use the vlan command to configure or create a VLAN on the switch. The
switch automatically enters the config-vlan mode.
3 Use the exit command when you are finished configuring the VLAN.
4 Use the interface port-channel command to enter the config-
interface mode to set the VLAN settings on a port, then use the pvid
command to set the VLAN ID you created for the port-list to that specific port in the
PVID table.
5 Use the inactive command to deactivate the VLAN(s).
Example:
Figure 158 Tagged VLAN Configuration and Activation Example
6 Configure your management VLAN.
• Use the vlan command to create a VLAN (VID 3 in this example) for
managing the switch, and the switch will activate the new management VLAN.
• Use the inactive command to disable the new management VLAN.
Example:
Figure 159 CPU VLAN Configuration and Activation Example
34.4 Global VLAN1Q Tagged VLAN Configuration Commands
This section shows you how to configure and monitor the IEEE 802.1Q Tagged VLAN.
sysname(config)# vlan 2000
sysname(config-vlan)# name upl
sysname(config-vlan)# fixed 5-7
sysname(config-vlan)# no untagged 5-7
sysname(config-vlan)# exit
sysname(config)# interface port-channel 5-7
sysname(config-interface)# pvid 2000
sysname(config-interface)# exit
sysname(config)#
sysname(config)# vlan 3
sysname(config-vlan)# inactive
sysname(config-vlan)#
