Chapter 4 Introducing the Web Configurator
GS-3012/GS-3012F User’s Guide
56
Port Setup
This link takes you to screens where you can configure settings for individual
switch ports.
Advanced Application
VLAN
This link takes you to screens where you can configure port-based or 802.1Q
VLAN (depending on what you configured in the Switch Setup menu).
Static MAC
Forwarding
This link takes you to screens where you can configure static MAC addresses
for a port. These static MAC addresses do not age out.
Filtering
This link takes you to a screen to set up filtering rules.
Spanning Tree
Protocol
This link takes you to screens where you can configure spanning tree settings to
prevent network loops.
Bandwidth Control
This link takes you to screens where you can cap the maximum bandwidth
allowed from specified source(s) to specified destination(s).
Broadcast Storm
Control
This link takes you to a screen to set up broadcast filters.
Mirroring
This link takes you to screens where you can copy traffic from one port or ports
to another port in order that you can examine the traffic from the first port
without interference
Link Aggregation
This link takes you to a screen where you can logically trunk physical links to
form one logical, higher-bandwidth link.
Port Authentication
This link takes you to a screen where you can configure RADIUS (Remote
Authentication Dial-In User Service), a protocol for user authentication that
allows you to use an external server to validate an unlimited number of users.
Port Security
This link takes you to a screen where you can activate MAC address learning
and set the maximum number of MAC addresses to learn on a port.
Classifier
This link takes you to a screen where you can configure classifiers.
Policy Rule
This link takes you to a screen where you can configure policy rules.
Queuing Method
This link takes you to a screen where you can configure SPQ or WRR with
associated queue weights for each port.
Multicast
This link takes you to a screen where you can configure various multicast
features and create multicast VLANs.
DHCP Relay
This link takes you to a screen where you can configure DHCP relay
information.
IP Application
Static Routing
This link takes you to screens where you can configure static routes. A static
route defines how the switch should forward traffic by configuring the TCP/IP
parameters manually.
Management
Maintenance
This link takes you to screens where you can perform firmware and
configuration file maintenance as well as reboot the system.
Access Control
This link takes you to screens where you can change the system login password
and configure SNMP and remote management.
Diagnostic
This link takes you to screens where you can view system logs and test port(s).
Syslog
This link takes you to screens where you can configure the device’s system
logging settings.
Cluster
Management
This link takes you to a screen where you can configure clustering management
and view its status.
Table 5 Navigation Panel Sub-link Descriptions (continued)
LABEL
DESCRIPTION
