Chapter 34 IEEE 802.1Q Tagged VLAN Commands
GS-3012/GS-3012F User’s Guide
264
An example is shown next.
For the
AdCtl section of the last column, “-“ is a port set to normal, “x” is a forbidden port
and “F” is a fixed port.
For the
TagCtl section of the last column, “T“ is a tagged port, “U” is an untagged port.
Figure 167 show vlan Command Example
sysname# show vlan
802.1Q VLAN Static Entry:
idx. Name VID Active AdCtl / TagCtl
---- ------------ ---- -------- ------------------------
0 1 1 active FFFFFFFFFFFFFFFFFFFFFFFFFFFF
UUUUUUUUUUUUUUUUUUUUUUUUUUUU
1 up1 2000 active -----------------------F----
TTTTTTTTTTTTTTTTTTTTTTTTTTTT
2 up1 2001 active ------------------------F---
TTTTTTTTTTTTTTTTTTTTTTTTUTTT
3 example 3 active -----------------------F----
TTTTTTTTTTTTTTTTTTTTTTTTTTTT
sysname#
