Chapter 21 Multicast
GS-3012/GS-3012F User’s Guide
157
21.7 MVR Group Configuration
All source ports and receiver ports belonging to a multicast group can receive multicast data
sent to this multicast group.
Configure MVR IP multicast group address(es) in the Group Configuration screen. Click
Group Configuration in the MVR screen.
Mode Specify the MVR mode on the switch. Choices are Dynamic and Compatible.
Select Dynamic to send IGMP reports to all MVR source ports in the multicast
VLAN.
Select Compatible to set the switch not to send IGMP reports.
Port This field displays the port number on the switch.
* Settings in this row apply to all ports.
Use this row only if you want to make some settings the same for all ports. Use this
row first to set the common settings and then make adjustments on a port-by-port
basis.
Note: Changes in this row are copied to all the ports as soon as you
make them.
Source Port This field is applicable for Ethernet ports.
Select this option to set this port as the MVR source port that sends and receives
multicast traffic. All source ports must belong to a single multicast VLAN.
Receiver Port Select this option to set this port as a receiver port that only receives multicast
traffic. A receiver port cannot belong to a multicast VLAN.
None Select this option to set the port not to participate in MVR. No MVR multicast traffic
is sent or received on this port.
Tagging Select this checkbox if you want the port to tag the VLAN ID in all outgoing frames
transmitted.
Add Click Add to save your changes to the switch’s run-time memory. The switch loses
these changes if it is turned off or loses power, so use the Save link on the top
navigation panel to save your changes to the non-volatile memory when you are
done configuring.
Cancel Click Cancel to discard all changes.
VLAN This field displays the multicast VLAN ID.
Active This field displays whether the multicast group is enabled or not.
Name This field displays the descriptive name for this setting.
Mode This field displays the MVR mode.
Source Port This field displays the source port number(s).
Receiver Port This field displays the receiver port number(s).
Delete To delete a multicast VLAN(s), select the rule(s) that you want to remove in the
Delete column, then click the Delete button.
Cancel Click Cancel to clear the Delete check boxes.
Table 54 MVR (continued)
LABEL DESCRIPTION
