Chapter 14 Mirroring
GS-3012/GS-3012F User’s Guide
118
The following table describes the related labels in this screen.
Table 33 Mirroring
LABEL DESCRIPTION
Active Clear this check box to deactivate port mirroring on the switch.
Monitor
Port
The monitor port is the port you copy the traffic to in order to examine it in more detail
without interfering with the traffic flow on the original port(s). Select this port from this drop-
down list box.
Port This field displays the port number.
* Settings in this row apply to all ports.
Use this row only if you want to make some settings the same for all ports. Use this row
first to set the common settings and then make adjustments on a port-by-port basis.
Note: Changes in this row are copied to all the ports as soon as you make
them.
Mirrored Select this option to mirror the traffic on a port.
Direction Specify the direction of the traffic to mirror. Choices are Egress (outgoing), Ingress
(incoming) and Both.
Apply Click Apply to save your changes to the switch’s run-time memory. The switch loses these
changes if it is turned off or loses power, so use the Save link on the top navigation panel
to save your changes to the non-volatile memory when you are done configuring.
Cancel Click Cancel to reset the fields.
