GS-3012/GS-3012F User’s Guide

65

C

H A P T E R

6

System Status and Port Details

This chapter describes the system status (web configurator home page) and port details
screens.

6.1 About System Statistics and Information

The status screen of the web configurator displays a port statistical summary with links to each
port showing statistical details.

6.2 Port Status Summary

To view the port statistics, click Status in all web configurator screens to display the Port
Status screen as shown next.

Figure 28 Port Status
