Chapter 6 System Status and Port Details
GS-3012/GS-3012F User’s Guide
67
Figure 29 Status: Port Details
The following table describes the labels in this screen.
Table 7 Status: Port Details
LABEL DESCRIPTION
Port Info
Port NO. This field identifies the Gigabit port described in this screen.
Name This field displays the port name you configured in the Port Setup screen.
Link This field shows whether the port connection is down, and the speed/duplex mode. It
also shows the cable type (Copper or Fiber) for the combo ports.
Status If STP (Spanning Tree Protocol) is enabled, this field displays the STP state of the port
(see Section 11.1.3 on page 105 for more information).
If STP is disabled, this field displays FORWARDING if the link is up, otherwise, it
displays STOP.
LACP This field shows if LACP is enabled on this port or not.
