Chapter 14 IPSec VPN
ZyWALL 2WG User’s Guide
282
14.10.1 VPN Log
The system log can often help to identify a configuration problem.
Use the web configurator LOGS Log Settings screen to enable IKE and IPSec logging at both
ends, clear the log and then build the tunnel.
View the log via the web configurator LOGS View Log screen or type
sys log disp
from
SMT Menu 24.8. See
for information on the log messages.
Figure 157 VPN Log Example
ras> sys log disp ike ipsec
# .time source destination notes
message
0|01/11/2001 18:47:22 |5.6.7.8 |5.1.2.3 |IKE
Rule [ex-1] Tunnel built successfully
1|01/11/2001 18:47:22 |5.6.7.8 |5.1.2.3 |IKE
The cookie pair is : 0xDAC0B43FBDE154F5 / 0xC5156C099C3F7DCA
2|01/11/2001 18:47:22 |5.6.7.8 |5.1.2.3 |IKE
Send:[HASH]
3|01/11/2001 18:47:22 |5.6.7.8 |5.1.2.3 |IKE
The cookie pair is : 0xDAC0B43FBDE154F5 / 0xC5156C099C3F7DCA
4|01/11/2001 18:47:22 |5.6.7.8 |5.1.2.3 |IKE
Adjust TCP MSS to 1398
5|01/11/2001 18:47:22 |5.1.2.3 |5.6.7.8 |IKE
Recv:[HASH][SA][NONCE][ID][ID]
6|01/11/2001 18:47:22 |5.1.2.3 |5.6.7.8 |IKE
The cookie pair is : 0xDAC0B43FBDE154F5 / 0xC5156C099C3F7DCA
7|01/11/2001 18:47:21 |5.6.7.8 |5.1.2.3 |IKE
IKE Packet Retransmit
8|01/11/2001 18:47:21 |5.6.7.8 |5.1.2.3 |IKE
The cookie pair is : 0xDAC0B43FBDE154F5 / 0xC5156C099C3F7DCA
9|01/11/2001 18:47:17 |5.6.7.8 |5.1.2.3 |IKE
Send:[HASH][SA][NONCE][ID][ID]
10|01/11/2001 18:47:17 |5.6.7.8 |5.1.2.3 |IKE
The cookie pair is : 0xDAC0B43FBDE154F5 / 0xC5156C099C3F7DCA
11|01/11/2001 18:47:17 |5.6.7.8 |5.1.2.3 |IKE
Start Phase 2: Quick Mode
12|01/11/2001 18:47:17 |5.6.7.8 |5.1.2.3 |IKE
The cookie pair is : 0xDAC0B43FBDE154F5 / 0xC5156C099C3F7DCA
13|01/11/2001 18:47:17 |5.6.7.8 |5.1.2.3 |IKE
Phase 1 IKE SA process done
14|01/11/2001 18:47:17 |5.6.7.8 |5.1.2.3 |IKE
The cookie pair is : 0xDAC0B43FBDE154F5 / 0xC5156C099C3F7DCA
15|01/11/2001 18:47:17 |5.1.2.3 |5.6.7.8 |IKE
Recv:[ID][HASH][NOTFY:INIT_CONTACT]9C3F7DCA
16|01/11/2001 18:47:17 |5.1.2.3 |5.6.7.8 |IKE
The cookie pair is : 0xDAC0B43FBDE154F5 / 0xC5156C099C3F7DCA
17|01/11/2001 18:47:15 |5.6.7.8 |5.1.2.3 |IKE
Send:[ID][HASH][NOTFY:INIT_CONTACT]9C3F7DCA
