Chapter 10 Wireless LAN
ZyWALL 2WG User’s Guide
175
Figure 83 NETWORK > WLAN
The following table describes the labels in this screen.
Table 51 NETWORK > WLAN
LABEL DESCRIPTION
WLAN TCP/IP
IP Address Type the IP address of your ZyWALL’s WLAN interface in dotted decimal notation.
Alternatively, click the right mouse button to copy and/or paste the IP address.
Note: Make sure the IP addresses of the LAN, WAN, WLAN and
DMZ are on separate subnets.
IP Subnet Mask The subnet mask specifies the network number portion of an IP address. Your
ZyWALL automatically calculates the subnet mask based on the IP address that
you assign. Unless you are implementing subnetting, use the subnet mask
computed by the ZyWALL.
RIP Direction RIP (Routing Information Protocol, RFC1058 and RFC 1389) allows a router to
exchange routing information with other routers. The RIP Direction field controls
the sending and receiving of RIP packets. Select the RIP direction from Both/In
Only/Out Only/None. When set to Both or Out Only, the ZyWALL will broadcast
its routing table periodically. When set to Both or In Only, it will incorporate the
RIP information that it receives; when set to None, it will not send any RIP packets
and will ignore any RIP packets received. Both is the default.
