DOCUMENT CENTRE CS 50 USER GUIDE 13–3 PROBLEM SOLVING
1
3
4
5
6
7
13
Paper Jam Clearance
Paper may jam in several areas inside the copier/
printer:
•
Behind the Left Door
•
Behind the Right Door
•
Behind the Front Door
•
In the Duplex Path
•
In the output area, that is, near the Output
Tray (or the Sorter/Mailbox)
•
Near the paper exit for Paper Tray 5
When a paper jam occurs, a message displays
in the message area of the Touch Screen with
the corrective actions to take, as illustrated in
Figure 3.
Occasionally, simultaneous paper jams occur or
multiple sheets of paper jam during an extended
copy job. The copier/printer will display a paper
jam message until all paper jams are cleared. The
Touch Screen displays the appropriate message
for the area of the copier/printer that needs to be
checked to clear a jam. Figure 3: A typical fault screen
