PAPER 9–12 DOCUMENT CENTRE CS 50 USER GUIDE
2
3
4
5
6
7
9
2 Place the stack of materials onto Paper Tray 5
between the edge guides, as illustrated in Figure
13. Slide the stack into the tray until it stops.
3 Move the back edge guide until it lightly touches
the side of the stack of materials. Readjust the left
edge guide each time you load materials into
Paper Tray 5.
4 Select the appropriate size and type for the stock
you have loaded. Refer to “Programming the
Paper Supply for Tray 5” for more information.
5 When you are done using Paper Tray 5, remove
all stock and store it appropriately. Close Paper
Tray 5 by gently pushing the plastic extensions to
the right as far as possible. Push Paper Tray 5
toward the copier/printer until it is securely in
place.
NOTE: In most cases you will never adjust the
front edge guide. Adjust the front edge guide only
for 12” x 18” paper.
Figure 13: Loading paper into Paper Tray 5
Edge guides
