DOCUMENT CENTRE CS 50 USER GUIDE 5–21 ADDED FEATURES
1
2
3
4
6
7
5
1 Touch the Margin Shift button on the Added
Features tab to display the Margin Shift screen as
illustrated in Figure 22.
2 Touch either the Side 1 or Side 2 button to display
the Margin Shift screen for the desired side.
3 Touch the Corner Shift button to display the
Corner Shift detail screen, as illustrated in Figure
23.
4 Touch the arrow button that illustrates the desired
location of the image on the output copy.
5 Touch Save to return to the Margin Shift screen.
6 If desired, repeat steps 2-5 for the other side.
7 Touch the button next to the icon that most closely
resembles the Original Orientation for the
document on the Document Glass.
8 Touch Save to return to the Added Features tab.
Figure 22: Margin Shift screen
Figure 23: Margin Shift screen with
Corner Shift selected
