PAPER 9–8 DOCUMENT CENTRE CS 50 USER GUIDE
2
3
4
5
6
7
9
Loading paper into trays 1, 2, 3, and 4
1 To load a paper tray, pull the tray out fully, as
illustrated in Figure 5.
2 Select the appropriate paper to load.
If you are not sure of the size to load, refer to the
Paper Supply feature on the Basic Copying tab to
check the size that was previously loaded in the
paper tray.
3 Load the desired size paper into the tray, as
illustrated in Figure 6.
Do not fill the paper tray above the fill line,
illustrated in Figure 6 and Figure 7.
Figure 5: A fully opened Paper Tray
Figure 6: Loading a Paper Tray
Fill line
