2000-A2-GB20-10 - 265 - February 2004
Connector
Pinouts This appendix specifies pinouts for each connector on the IAD.
' &RQQHFWRU 3LQRXWV
Table D–1. RS-232 DB-9 Console Port Pin Assignments
Pin Signal
1 Ground
2 Tx Data
3 Rx Data
Table D–2. RJ11 POTS Port Pin Assignments
Line
Pin Assignment
Line
Pin Assignment
Tip Ring Tip Ring
1 3 4 5 2 5
2 3 4 6 2 5
3 3 4 7 2 5
4 3 4 8 2 5
Table D–3. RJ45 BRI ISDN S0 Port Pin Assignments
Line
Pin Assignment
Line
Pin Assignment
Tip Ring Tip Ring
1 3 4 5 2 5
2 3 4 6 2 5
3 3 4 7 2 5
4 3 4 8 2 5
