2000-A2-GB20-10 - 86 - February 2004
Displaying F4 OAM Configuration
To display the F4 OAM Type currently set, type 4. The IAD displays the
status message, and then displays the ATM Configuration menu:
F4 End to end OAM VPI 0
Sending OAM Loopback
To send an OAM Loopback:
1. On the ATM Configuration menu, type 5 to select Send OAM
Loopback.
2. The IAD displays a list of all configured F4 OAM ports and VPI values:
Select Port:
1. F5 OAM VCC: 0*40
2. F5 OAM VCC: 100*39
3. F4 OAM VPI: 0
Type the port on which to send the OAM Loopback and press Enter.
3. The IAD performs a loopback test on the selected port and reports the
successful results:
Loopback on 0*38 response received in 5ms.
—or unsuccessful results—
Loopback on 0*40 timeout error
4. Press any key to display the ATM Configuration menu.
Configuring EmptyCells
1. On the ATM Configuration menu, type 6 to select Configure
EmptyCells.
2. The IAD displays the following instructions.
Empty Cells are currently IDLE
Enter 1 for IDLE cells or 2 for UNASSIGNED cells:
Type 1 to select Idle cells, or type 2 to select Unassigned cells.
3. Reset the IAD (page 14 ) when you finish ATM configuration.
Configuring
Frame
Relay
DLCIs
To configure Frame Relay DLCIs, type 3 on the WAN Configuration menu.
The IAD displays the Frame Relay DLCI Configuration menu:
Figure 4–56. Frame Relay DLCI Configuration Menu
To perform these tasks, type the option and proceed to the corresponding
section. The tasks in this section are described beginning at the FR DLCI
Configuration menu.
‹ Adding a New DLCI ( Adding a DLCI on page 88 )
*****************************************
FR DLCI Config Menu
*****************************************
1. Add New DLCI
2. Modify Existing DLCI
3. Delete DLCI
4. Show Current DLCIs
