292
A Server Specifications
A Server Specifications
This section explains the specifications for the server.
The specifications for the server are subject to change for the purpose of improvement without prior notice.
table: Server Specifications - Diskless Type
Item Functions and Specifications
Type Diskless type
Model PGUR2023AA
CPU
Standard 64-bit Intel® Processor Xeon™ 3E GHz / 2MB
With the
conversion kit 64-bit Intel® Processor Xeon™ 3.20E GHz / 2MB
64-bit Intel® Processor Xeon™ 3.60E GHz / 2MB
Number of
multiplication
1 (Max. 2)
Memory
modules
Standard 1GB (512MB-DDR2 DIMM × 2)
Adding size 1GB / 2GB / 4GB (installed in a pair)
Maximum 16GB (8 slots, 1GB DIMM × 8)
Video RAM capacity 8MB
Graphics
VGA chip: ATI RAGE XL
648 Ч 480, 800 Ч 600, 1024 Ч 768, 1280 Ч 1024
Displayed colors: Differ depending on resolution and OS
CD-ROM drive bay
1 bay (optional)
Types: 24 × CD-ROM unit (IDE)
3.5-inch storage bay 2 bays
Standard Optional
Adding size
73.4GB /146.8GB /300GB (10,000rpmm, Ultra320 SCSI)
73.4GB (15,000rpm, Ultra320 SCSI)
Maximum 300GB
× 2 = 600GB
Disk array Standard (onboard SCSI array controller)
Expansion slots
PCI-X × 2
64-bit/133MHz × 1 (PCI-X, Full-Height, Half-length/LowProfile),
64-bit/66MHz × 1 (LowProfile)
Floppy disk drive 3.5 inch (2 mode 1.44MB/720KB) (Standard)
SCSI interface Ultra320 SCSI
× 1 (standard feature of the baseboard)
Network LAN (1000BASE-T / 100BASE-TX / 10BASE-T) × 2 (standard feature of the baseboard)
Interface LAN × 2, serial × 1, keyboard, mouse, monitor, USB × 3
Keyboard and Mouse Option
Dimension (mm)
Width 430 (482) × Depth 710 (770) × Height 43.6 (1U unit)
Values in parentheses are dimensions including projections.
Weight Max. 19kg
Internal clock precision ± 2 - 3 minutes/month
Power consumption Max. 500W/1800kJ/h
Power 100V-240V AC (50/60Hz) / bipolar ground type
Power supply unit Standard: 1, Max.: 2 (when the redundancy option is installed)
Fan
15 (CPU fan × 10, power supply fan × 4, system fan × 1)
Only CPU/power supply fans are redundant.
OS
Windows Server 2003, Standard Edition / Windows Server 2003, Enterprise Edition /
Windows 2000 Server / Windows 2000 Advanced Server /
Red Hat Enterprise Linux AS / Red Hat Enterprise Linux ES
