228
Chapter 8 Hardware Configuration/Utilities
8.2.14 Memory Status Submenu
Appears when [Memory Status] is selected from the [Server] menu.
This submenu sets whether or not to allow the use of the installed memory.
table: Items on the Memory Status Submenu
Item Setting Description
DIMM A1 • Enabled (at the time of
purchase)
• Disabled
• Failed
Sets whether or not to allow the use of memory in
Memory Slots A1 to B4.
For memory slot locations, refer to "7.4.1 Where to
Install the Memory Modules" ( pg.175).
This must not be set to [Disabled] or [Failed].
DIMM A2
DIMM A3
DIMM A4
DIMM B1
DIMM B2
DIMM B3
DIMM B4
Item Specific Help
PhoenixBIOS Setup Utility
Server
Memory Status
Select Sub-Menu
F1
Esc
Select Item
Select Menu
Change Values -/+
Enter
Info
Exit
F9
F10
Setup Defaults
Save and Exit
ChannelA
DIMM A1: [Enabled]
DIMM A2: [Enabled]
ChannelB
DIMM B3: [Enabled]
DIMM B4: [Enabled]
DIMM A3: [Enabled]
DIMM A4: [Enabled]
DIMM B2: [Enabled]
DIMM B1: [Enabled]
