Creating a Picture-in-picture (PIP) Scene
1. At the upper left corner of the App, tap .
2. Tap at the bottom of the scene list.
3. At the upper part of the image editing page, tap and then tap
.
4. Tap within the big frame in the canvas, and tap a thumbnail at the bottom
to add it as the big picture.
You can also drag the thumbnail to the big frame.
5. Tap within the small frame, and tap a thumbnail at the bottom to add it as
the small picture.
You can also drag the thumbnail to the small frame.
The small picture is at the lower left corner by default and retains the
aspect ratio of the source.
6. Tap within either frame, and use gestures or the scene editing tools at the
upper part of the page to edit the scene.
For editing details, see Editing a Scene .
Besides common editing tools, a PIP scene also supports editing the small
frame , scaling the small picture , changing the small picture position .
7. Tap Done at the upper right corner.
The added scene will be displayed in the scene list and named as Scene X .
8. (Optional) Repeat the above steps to add more scenes.
A thumbnail can be added to only one frame. Only one of the two
frames can contain a video file resource.
