24: A NALOG I/O C ONTROL
24-10 « FC4A M ICRO S MART U SER ’ S M ANUAL »
Ladder Refresh Type Analog Output Module Data Register Allocation (FC4A-K2C1)
Data Register
Number Offset
Data Size
(word)
Parameter Channel Default R/W
+0 (Low Byte)
1
Analog output signal type CH0 FFh
R/W
+0 (High Byte) — Reser ved — All channels 00h
+1 3 Analog output data configuration CH0 0 R/W
+4 1 Analog output signal type
CH1
00FFh R/W
+5 3 Analog output data configuration 0 R/W
+8 1
Analog output data
CH0 0 R/W
+9 1 CH1 0 R/W
+10 1
Analog output operating status
CH0 — R
+11 1 CH1 — R
+12 3 — Reser ved — All channels — R
