12
a
Pull the media up and, holding it from the sides, align its right edge with
the perforated line on the entry platen.
b
Insert the leading edge into the plotter, until the page buckles slightly.
c
Release the media when the plotter begins to pull it in.
1839
13
Press the
↓
key next to the front-panel display to indicate you are loading roll
media.
Sheet load
Roll load
↓
↑
––––––––>
––––––––>
0014
MEDIA
AND
CAR
TRIDGES
3
Working With Media and Cartridge(s)
Loading Media
