If There are Blurred Lines (Ink “Bleeds” from Lines)

Perhaps you are not using HP media. For details of HP media, see page 3-3 and
the Supplies Source catalog supplied with the plotter.

The plotter may be operating in an area where the temperature and humidity are
too high. For environmental specifications, see page 11-4. To allow for
extremely dry or humid environments within the specification, see page 3-22.

Did you adjust the drying time in the front-panel menu purely to speed up the
plotters output? For details of drying time adjustments see page 3-23.

If There are Blotchy Areas (Uneven Fill Density)

Perhaps you are not using HP media. For details of HP media, see page 3-3 and
the Supplies Source catalog supplied with the plotter.

Did you specify the right media type when loading the media? For details of
front-panel media types, see page 3-3. To find out the plotter’s current type of
media setting, see page 7-2.

Note that some media types are not recommended for color plots with large area
fills. See page 3-5.

If the Plot Is Too Dark or the Color Too Saturated

You can make a global adjustment to the amount of black ink used (which
affects most colors too) by adjusting the

Lightness

setting. See page 5-8.
