Message
Explanation and
Action
Lower lever
to continue
You lifted the media lever while the processor was busy.
Lower the lever to
continue.
Lower window
to continue
You opened the window while the processor was busy.
Close the window to
continue.
Media too small
The media you loaded for accuracy calibration or cartridge alignment is too small.
Reload appropriate media. See page 7-5.
Mispositioned
Reload roll
The roll is mispositioned.
Reload media.
Mispositioned
Reload sheet
The sheet is mispositioned.
Remove it and reload it with the right edge no more
than 0.2 inches (0.5 cm) from either side of the perforated line on the entry platen.
MIO data error
The modular interface is incorrectly configured.
Press
Enter
to clear the message
from the front panel display. Recheck the MIO configuration settings.
MIO error
Communication
Break
The flow of data from the computer to the plotter was prematurely stopped (e.g.,
by turning off the computer before all data is sent).
Press
Enter
to clear the
message from the front panel display.
Open window to
access cartridge(s)
Lift the window to access the cartridge(s).
Out of memory
Data was lost
The current plot is too large for the plotter’s buffer.
Install additional memory to
plot this drawing.
Pull
#
/ Align
$
edges to roll
Grasp the left and right free edges of the roll media and pull toward you until the
media is taut. At the same time, align the left and right edges of the media so that
they are flush with the left and right edges of the roll.
Remove media
The ink is dry.
Remove the calibration plot the plotter just produced. Press
↓
to
continue with accuracy calibration.
Remove media
Lower lever
You have attempted to load media while the lever at the right of the plotter was
raised.
Remove the media, lower the lever, and reload media with the lever down.
Replace cartridge(s)
nnn
n
The cartridge indicated has a clogged nozzle.
Replace it to continue.
Reseat cartridge(s)
nnn
n
The cartridge indicated is badly seated. R
eseat it to continue.
Roll misaligned
Reload roll
Roll media is misaligned (skewed).
Reload media.
RS-232 error
Baud, parity
The RS-232-C interface is configured incorrectly.
Press
Enter
to clear the
message from the front panel display. Check the baud rate and parity settings in
the front panel, in the hardware configuration, and in your software to be sure they
are all compatible.
