If the Plotter Waits Too Long to Plot a Nest

Change the

Nest wait

setting. See page 6-12.

If the Plotter Performs the Cartridge Alignment Routine
Unexpectedly

This is a normal plotter operation. The plotter will align the cartridge(s) every
time you replace, or even reseat, a cartridge, whether or not it is new.

If the Bail (Black Metal Bar) Does Not Lower All the Way

If the the bail (the black metal bar just inside the plotter’s window) will not
lower all the way, check for obstructions underneath it.

Make sure the cutting carriage is pushed all the way to the right.

Troubleshooting

Solving Miscellaneous Problems
