14 June 2011 K2 Dyno Controller Operator Manual 97
Setting the Auxiliary Audio
2. After editing the information by touching each panel, touch Back .
To add auxiliary audio, see “Setting the Auxiliary Audio” .
Setting the Auxiliary Audio
The auxiliary audio lets you play music behind a video. For example, when you create
a playlist, you could add an auxilary audio track to play an introduction to the video.
1. In the Home screen, touch the Audio Meters panel.
2. Touch Show Aux .
The Auxiliary Audio screen opens.
3. Make the following selections:
(2) Audio gain controls Sets an audio level. Use the +/- controls to increase or decrease the
audio level
Mute : Mutes the audio. You can mute the audio without changing the
set values even when the audio levels for the selected channels or audio
tracks are not the same.
Restore : sets all the audio levels for the selected audio tracks to 0 dB.
(3) Audio Meters display The audio level for each audio track is shown at the top.
Touching
All toggles between all selected and all deselected.
(4) Audio track selection Select the audio tracks to be set.
If you select
Show All , you must select or deselect the tracks
individually.
If no audio tracks are selected, the Audio Meters panel on the Home
screen is blank.
(5) BACK Return to previous screen with any changes to the audio settings saved.
SHOW AUX Opens the Auxiliary Audio screen.
Name Function
