30 K2 Dyno Controller Operator Manual 14 June 2011
Chapter 2 Starting Up and Shutting Down
Multichannel + gang mode
2 Record, 2 Playback. Player channels in sync.
• The 2 Record and 2 Playback channel set-up is done when the session is configured
at start-up screen
• A,B, angles can be selected for playback on the P1, (C3) or P2 (C4)
• Gang operation is based on Independent mode with selection of both channels and
turning on gang
Preview/Program mode
2 Record, 1 Playback/PGM, 1 Preview.
• The 2 Record and 2 Playback channel set-up is done when the session is configured
at start-up screen
• A,B, angles can be selected for playback on the C Program (C3) and D (C4) Preview
• In this mode, the PVW button illuminates yellow when PGM is selected. PVW lights
green when selected and the Take button illuminates green to indicate ready for Take
to PGM channel.
• P1 and P2 playout channel content can be “swapped” by pressing buttons Fn then
Take.
A
Record Record
Play Play
P2 gang P1 gang
C1
C4
P2
C3
P1
B
C2
Cue A or B angle on P1
or P2 channel.
Playback independently
then put in Gang mode.
Press both P1 and
P2 buttons at same
time to enter Gang
mode. Press P1 or
P2 to get out of
Mutichannel mode.
A
Record Record
Play Play
PVW PGM
C1
C4
P2
C3
P1
TAKE
B
C2
Toggle Preview
control mode
on and off.
Press Shift
then PVW or
PGM button
Cue A or B angle on
Preview channel.
Press Take to
put Preview
cued point onto
Program.
