9-2
Installing the AO-10 Analog Output
Module
LonPoint AO-10 Analog Output Module
The front panel of the AO-10 module is shown in figure 9.1. There are no
front panel LEDs associated with the outputs, however, there are user-
configured jumper blocks that must be set correctly for each analog output.
Lo
nP
oi
nt
™
In
te
rfa
ce
Network Access Jack; Use
With Echelon PCC-10 Cable
Model 78303
Peel-Off Code 39
Format Bar Code of
LonPoint Interface
Neuron Chip ID
Number
LonPoint Interface
Model and Software
Revision Numbers
Service LED
Service Switch
Power/Wink LED:
Power ON: Illuminated Continuously
Wink: Flashing
Analog Output 1
Analog Output 2
Analog Output Identifier
(No LEDs For Analog Outputs)
1
2
1
2
AO-10
MODEL 41400 9760
SW VERSION 3.0
ID NUMBER
OUTPUT: 1012VDC, 0-20mA EACH
LISTED 178K
ENERGY MANAGEMENT
EQUIPMENT SUBASSEMBLY
AO-10 MODEL 41400 ID NUMBER
AO-10 MODEL 41400 ID NUMBER
E
c
us
m
L
U
®
Figure 9.1 LonPoint AO-10 Analog Input Module - Front Panel
The AO-10 module includes two 4 x 2 jumper blocks for each output. These jumper
blocks, labeled 0-10V and 4-20mA, are used to configure the module for the type of
analog output signal that will be generated (figure 9.2); using an incorrect jumper
setting will result in improper output signals. Each of the two outputs may be
