8-6 Installing the AI-10 Analog Input Module
I/O type 0 to 156mV
0 to 625mV
0 to 10V
0 to 20V
0 to 24mA
0 - 12.5µA
0 - 781µA
0 - 19.5µA
Resistive transducer ranging from 100• to 15k•, nominal
I/O resolution 0 to 20VDC: 0.3mV resolution
0 to 24mA: 0.37µA resolution
I/O isolation 100V, transformer isolation. Inputs are isolated from the input
power and the network but not from each other.
Transceiver type FTT-10A with blocking capacitors for compatibility with link
power channel
Network connector Phone plug connector accessible from front panel
Input power 16-30VAC or VDC, internally isolated power supply—2.1VA for
all modes except 2-wire mode (4.5VA)
Mounting Type 1 or Type 1D Base Plate
Temperature -40 to +85°C, operating and non-operating
Humidity 10 to 95% RH @ 50°C
EMI FCC A, CE Mark
Safety agency UL 916
Function Blocks Node object (1), analog input open-loop sensor objects (2),
digital encoder controller objects (2), analog function block
controller objects (4), type translators (4)
Software Configuration Wide variety of L ON M ARK Standard Configuration Parameter
Types supported by direct memory read/write function of LNS
compatible network management tools
AI-10 Module Software Settings
The software settings of the AI-10 module are described in the LonPoint Application
and Plug-In Guide.
Installing the AI-10 Module
Installation of the AI-10 module involves the following steps:
1. Ensure that the Base Plate has been wired and installed correctly, and is
securely fastened to the electrical enclosure.
2. Check for continuity on all network and power wiring. Ensure that the correct
sensors are connected to the correct Base Plate I/O terminals.
3. Make certain that all network channels are terminated with the correct number
and type of Terminator.
4. Insert the AI-10 module into Base Plate by aligning the network access jack on
the AI-10 with the arrow head on the Base Plate (the arrow should point in the
