2-10 LonPoint Modules and Base Plates
Power or Power/Wink LED
Every module includes either a power LED or a combination power/wink LED. The
wink function is used by a network management/installation tool to visually identify a
particular module; the wink command causes the power LED to blink.
I/O Number
1
2
3
4
Every input and output symbol is accompanied by an I/O Number designating which
hardware input or output the function is associated. The DI-10 has four inputs, the DO-
10 has four outputs, the DIO-10 has two inputs and two outputs, the AI-10 has two
inputs, and the AO-10 has two outputs.
Digital Input
This symbol designates the I/O as a digital input and is accompanied by an I/O Number.
Digital Output
This symbol designates the I/O as a digital or relay output and is accompanied by an I/O
Number.
Analog Input
This symbol designates the I/O as an analog input and is accompanied by an I/O
Number.
