04/15/99Installing the LPR Router Modules 11-5
Installing the LPR Router
Installation of the LPR-1X module involves the following steps:
1. Ensure that the Type 2 or Type 2D Base Plate has been wired and installed
correctly, and is securely fastened to the electrical enclosure.
2. Check for continuity on all network and power wiring. There are no I/O
connections on a Type 2 or Type 2D Base Plate.
3. Make certain that all network channels are terminated with the correct number
and type of terminator. Terminator(s) may be installed in unused screw
terminals at end of network run(s).
4. Insert the LPR Router into the Base Plate by aligning the network access jacks
on the LPR Router with the arrow head on the Base Plate (the arrow should
point in the direction of the jacks), and then pressing firmly to ensure that the
module is properly seated in its mating Base Plate connector.
5. The LPR Router can be hot-plugged: there is no need to disconnect power when
installing the module. If power is present then the Power LED will illuminate
continuously. If power is not present then the Power LED will remain off.
6. Securely attach the LPR Router to the Base Plate by screwing the two Echelon
205-0130-01 screws (8-32 [M8], 3/8” [9.5mm]) into the threaded inserts in the
Base Plate. Use approximately 4 lbs. in/0.5Nm torque on the screws.
7. Follow the router configuration procedure described in the LonMaker for
Windows User’s Guide to configure the software in the LPR Router.
8. See Troubleshooting for assistance with improper LPR Router operation.
