04/15/99Installing the LPR Router Modules 11-3
Lo
nP
oi
nt
™
R
ou
te
r
Peel-Off Code 39
Format Bar Code of
LonPoint Interface
Neuron Chip ID
Number
LonPoint Interface
Model and Software
Revision Numbers
Service
Switch
Power LED:
Power ON: Illuminated Continuously
Network Access Jacks; Use
With Echelon PCC-10 Cable
Model 78303
Channel A
Channel B
Channel A
Channel B
Service
LEDs
Packet Activity LED
Router Transferring Packets: Flashing
A B
B A
B
A
B
A
LPR-10
MODEL 42100 972
TP/FT-10 TP/FT-10
ID NUMBER
NETWORK: 10Vp-p
UL UL c
LISTED 178K
ENERGY MANAGEMENT
EQUIPMENT SUBASSEMBLY
LPR-10 MODEL 42100 ID NUMBER
LPR-10 MODEL 42100 ID NUMBER
Figure 11.1 LonPoint LPR Router Module - Front Panel
All LPR Routers are installed in a Type 2 or Type 2D Base Plate. Wiring connections to the
LPR Routers are presented in table 11.1. Specifications for the routers are shown in table
11.2.
