Echelon LonPoint Module - Manual (Page 81)

LonPoint Hardware Guide 7-3
Lo
nP
oi
nt
™
In
te
rfa
ce
Network Access Jack; Use
With Echelon PCC-10 Cable
Model 78303
Peel-Off Code 39
Format Bar Code of
LonPoint Interface
Neuron Chip ID
Number
LonPoint Interface
Model and Software
Revision
Service LED
Service Switch
Power/Wink LED:
Power ON: Illuminated Continuously
Wink: Flashing
Digital Output Status LEDs
Hand/Off/Auto Switch
1 ON (Hand)
0 OFF (Off)
Network Controlled (Auto)
Digital Output 1 Switch
Digital Output 2 Switch
Digital Output 3 Switch
Digital Output 4 Switch
1 2 3 4
1
0
1 2 3 4
1
2
3
4
1
2
3
4
Digital Output 1 LED
Digital Output 2 LED
Digital Output 3 LED
Digital Output 4 LED 1
2
3
4
DO-10
MODEL 41200 9745
SW VERSION 3.0
ID NUMBER
OUTPUT: 0-12VDC, 25mA EACH LISTED 178K
ENERGY MANAGEMENT
EQUIPMENT SUBASSEMBLY
DO-10 MODEL 41200 ID NUMBER
DO-10 MODEL 41200 ID NUMBER
c us
m
L U
®
E
Figure 7.1 LonPoint DO-10 Digital Output Module - Front Panel
