Modem Ctrl
xxx
On
Off
Activates the following signals:
RTS (Request to Send)
CTS (Clear to Send)
Disables the above signals (RTS is held high)
MENU 6: PARALLEL CONTROL
Printer Displays Values Description
Handshk on xxxx
Busy
< or >
Ack
Parallel interface handshaking
Active when:
Buffer filled to high water mark
Printer off line
Paper out condition
Error conditions
Inactive when:
buffer below low water mark
Ack xxxxxx Busy After
Before
Ack will occur after busy.
Ack will occur before busy.
8th Bit xxxxxxx Enable
Disable
Printer will honor the 8th bit.
Printer will ignore the 8th bit.
Parallel xxxxxxx Enable
Disable
Parallel port is enabled.
Parallel port is disabled.
The printer will ignore any data sent to the parallel port.
Handshaking will indicate busy.
4-19
