AMT Datasouth Documax A6300 User Manual
Page 130
1
Frame Ground
2
Transmitted Data
3
Received Data
*4
Request To Send
*5
Clear To Send
*6
Data Set Ready
7
Signal Ground
*8
Data Carrier Detects
9
No Connect
10
No Connect
11
Data Terminal Ready
12
No Connect
13
No Connect
14
Reserved
15
Reserved
16
Reserved
17
Reserved
18
Reserved
19
Reserved
20
Data Terminal Ready
21
No Connect
22
No Connect
23
No Connect
24
No Connect
25
No Connect
*These signals are available only when the Modem Control feature is enabled.
