MENU 5: SERIAL CONTROL
Printer Displays Values Description
Baud Rate xxxx 110
300
600
1200
1800
2400
4800
9600
19.2k
Refer to the documentation of your host computer to
determine the baud rate.
Serial xxxxxx RS-232
RS-422
OFF
Selects serial configuration
Cable must be configured to match. See Appendix B.
Selecting OFF disables both serial configurations.
Parity xxxxx None
Even
Odd
Space
Mark
Refer to the documentation for your host computer to
determine parity.
Space 8th Bit only
Mark 8th Bit only
Data Bits xxxxxxx 7
8 Refer to the documentation for your host computer to
determine data bits.
DTR xxxxxxx
Enable
Disable
Hardware Handshaking
DTR (Data Terminal Ready)
Busy on when:
Buffer filled to high water mark
Printer off line
Paper out condition
Error conditions
Busy off when:
buffer below low water mark
Will remain high at all times
Handshk xxxxxxx ENQ_ACK
ETX_ACK
X-ON/
X-OFF
XON+ETX
XON+ENQ
NONE
Specifies whether to use software handshaking
X-ON Ctrl xxx Single
Robust
Specifies which type of X-ON handshaking control is active
X-OFF Ctrl xxx Single
Robust
Specifies which type of X-OFF handshaking control is active
4-18
