AMT Datasouth Documax A6300 User Manual
Page 131
RS-422 Serial Interface Connector Pin Assignment
PIN
SIGNAL NAME
1
Frame Ground
2
Reserved
3
Reserved
4
Reserved
5
Reserved
6
Reserved
7
Signal Ground
8
Reserved
9
No Connect
10
No Connect
11
No Connect
12
No Connect
13
No Connect
14
Transmitted Data (+)
15
Transmitted Data (-)
16
Received Data (+)
17
Received Data (-)
18
Data Terminal Ready (+)
19
Data Terminal Ready (-)
20
Reserved
21
No Connect
22
No Connect
23
No Connect
24
No Connect
25
No Connect
B-11
