3.3 Load Forms
NOTE
To load the main tractor path on Dual Path printer,
place alternate path tractors in center position. Main
tractor doors cannot be opened with alternate tractors
aligned in front. (Hint: Use least frequently changed
paper in main tractors and frequently changed paper or
narrow stock in the alternate path.) If both paths are
used, main tractor path must be loaded first.
NOTE
If paper is to be loaded into alternate path, align the left
tractors with alignment mark on printer for both feed
paths before loading front most forms.
NOTE
Form Thickness Adjustment Knob automatically
retracts printhead to allow for forms loading and
repositions to print position after loading.
To access the tractors and load a continuous form into either tractor, proceed as follows:
(For cut sheet forms, go directly to Step 8.)
1. Unlock both tractors by rotating the locking levers.
2. Align the left tractor with the alignment mark located on the body of the printer.
Lock left tractor in place. Place the right tractor at the approximate forms width.
3. Position the front paper guides and rear paper supports, on main path, equally
across width of form. (Hint: For easy movement, grab the front paper guides and
push up while sliding.)
3-3
CAUTION
PRINTING PAST THE EDGE OF THE
FORM DUE TO IMPROPER TRACTOR
LOCATION CAN CAUSE DAMAGE TO
THE PRINTHEAD.
