Following is an example of some common forms used and specific features that may be
programmed into a profile when using these forms. For more information refer to Section
3.13 “Selecting Paper Paths Using The Profile Key”.
Profile Name/Feature Value
Feature Name P1
"Report"
P2
"Invoice"
P3
"Checks"
P4
"Statements"
Form Length 88 66 24 30
Lines/Inch 8 6 6 6
Right Margin 136 80 70 70
Horz Adj 0/144 5/144 8/144 12/144
Manual Tear FF TOF TOF TOF
Emulate IBM PRO IBM PRO LA 120 LA 120
Font DP 18 Draft 10 OCR A Draft 10
Parallel Enable Disable Disable Enable
Path Main Either Alternate Alternate
In this sample, to change from printing "Report" to "Checks" do the following:
1. Take printer off line by pressing the On/Off Line key.
2. Park current form.
3. Change to the desired profile, in this case "Checks".
4. Load the appropriate forms ("Checks").
5. Place unit on line.
The Path feature specifies which paper path is selected. Profile 1 named “Report” selects
the main path. Selecting Profile 2 leaves the path unchanged. Selecting Profile 3 and 4
selects the alternate path.
For an application that is not stored in a profile, call up the profile whose features most
closely match the application and reprogram only the features requiring change. These
changes will not alter the profile's permanent settings unless you save them when you exit
Setup Mode.
4-2
4.3 Setup Mode Key Functions
To change features, open the Keypad Door to enter Setup Mode. Figure 4-1 shows the
Setup Mode keys and their respective functions.
A brief description of each key function follows.
