Table 3.2 Parallel Interface Connector Pin Assignment
Pin Number
Assianment
1
Data Strobe
2
Data Bit 1
3
Data Bit 2
4
Data Bit 3
5
Data Bit 4
6
Data Bit 5
7
Data Bit 6
8
Data Bit 7
9
Data Bit 8
10
Acknowledge
11
Busy
12
Paper Out of Print Off
13
+5
14
Ground
15
—
16
Ground
17
Chassis Ground
18
+5V
19
*Twisted Pair Ground
20
•Twisted Pair Ground
21
•Twisted Pair Ground
22
•Twisted Pair Ground
23
•Twisted Pair Ground
